A robust 2-piece design ball valve offering reliable shut-off performance with easy maintenance, suitable for a wide range of industrial piping applications.
PRODUCT DESCRIPTION |
|
| BODY | CAST IRON | CAST STEEL | SS 304 | SS 316 | SS 316L |
| BALL | AISI 410 | AISI 304 | AISI 316 | SS 304L | SS 316L |
| STEM | SS 410 | SS 304 | SS 316 | SS 304L | SS 316L |
| SEAT & SEAL | PTFE | RPTFE | GFT | TEFLON | VITON | METAL TO METAL |
| MFG STD | BS 5351 |
| TEST STD | BS 6755 |
| END CONNECTION | SCREWED END TO BSP, NPT (F) | SOCKETWELD END |
| HYD TEST PRESSURE | BODY: 425 PSIG (30 KG/CM2) SEAT: 300 PSIG (21 KG/CM2) |
| OPERATION | LEVER |
| TYPE | SINGLE PIECE | TWO PIECE | THREE PIECE | 3 WAY | 4 WAY |
| SIZE RANGE | 15 MM TO 300 MM |
MATERIAL DETAIL |
||||||
| PART NO. | PART NAME | CAST IRON | CAST STEEL (WCB) | MS | CF8 | CF8M |
| 01 | BODY | IS 210 GR FG 200 | ASTM A 216 GR WCB | MS – EN8 | A 351 CF8 | A 351 CF8M |
| 02 | CONNECTORS | IS 210 GR FG 200 | ASTM A 216 GR WCB | MS – EN8 | A 351 CF8 | A 351 CF8M |
| 03 | BALL | AISI 304 / AISI 316 / S.S.304 / S.S.316 | S.S.304/ CF3 | S.S.316/ CF3M | ||
| 04 | STEM | AISI 304 / AISI 316 / S.S.304 / S.S.316 | S.S.304 / CF3 | S.S.316 / CF3M | ||
| 05 | GLAND | AISI 304 / AISI 316 / S.S.304 / S.S.316 | ||||
| 06 | BALL SEALS | PTFE / RPFE / VITON / EPDM (on Request) | ||||
| 07 | BODY SEALS | PTFE / RPFE / VITON / EPDM (on Request) | ||||
| 08 | STEM PACKING | PTFE / RPFE / VITON / EPDM (on Request) | ||||
| 09 | GLAND PACKINGS | PTFE / RPFE / VITON / EPDM (on Request) | ||||
| 10 | GLAND NUT & STEM NUT | AISI 410 / AISI 304 / AISI 316 | ||||
| 11 | HANDLE | S.S. / M.S. / C.S. | ||||
| 12 | SLEEVE | PVC | ||||
| 13 | BODY STUDS & NUTS | ASTM A 193 Gr. B7 / ASTM A 194 Gr. 2H / S.S. / C.S. | ||||
Allied Engineering India manufactures a wide range of industrial valves including Gate Valves, Globe Valves, Check Valves, Ball Valves, Butterfly Valves, and Plug Valves. Our valves are available in various materials such as Cast Steel (WCB), Stainless Steel, and Carbon Steel to suit diverse industrial applications.
All our products are manufactured in compliance with international standards including API, ANSI, BS, DIN, and IS specifications. Every valve undergoes rigorous quality checks from raw material inspection and dimensional verification to hydrostatic pressure testing, ensuring reliable performance under demanding conditions.
Lead times vary depending on the product type, specifications, and order quantity. Standard products are typically available within 2-4 weeks, while custom-manufactured valves may require 4-8 weeks. We recommend contacting our sales team for an accurate delivery schedule based on your specific requirements.
